ID Tech MINIMAG User Manual

22
Section 6
TROUBLESHOOTING
The MiniMag reader is easy to install and use. Most problems encoun-
tered can be attributed to:
• Incorrect Interface Cabling
• Incorrect Configuration Setup
• Bad Magnetic Stripe Quality
General Procedures
The troubleshooting process can be simplified by following these
simple diagnostic procedures.
1. The unit should emit one long beep when power is first applied. If it
does not, then the unit is not receiving power.
2. Once it has been confirmed that the unit is correctly powered, try
swiping a credit card. The LED will go off while decoding, then light
green to indicate a “good read,” or red to indicate a “bad read.”
3. Once the unit has indicated a “good read,” then proceed to check the
interface cabling connections.

ID Tech MINIMAG Specifications

General

Interface	TTL
Scan speed (max)	76.2 mm/sec
Operating voltage	5 V
Power consumption	4 mA
LED indicators	Yes
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Cable length	1.8 m

Weight and Dimensions

Weight	130 g
Dimensions (WxDxH)	34 x 90 x 28 mm
