SHORT LIST OF PARTS
ESPRIT 2 - Installation and Servicing
When ordering spares please quote:
1. Boiler model
2. Appliance G.C. No.
3. Description.
4. Quantity.
5. Product number.
The following are parts commonly required due to damage or
expendability. Their failure or absence is likely to affect safety or
performance of this appliance.
The list is extracted from the British Gas List of Parts, which
contains all available spare parts.
The full list is held by British Gas Services, Ideal Stelrad Group
distributors and merchants.
Key No. G.C. Part No. Description Qty. Product Number
1 HO7-768 Front casing panel 1 173 509
4 H66-557 Bottom casing panel 1 175 414
11 E67-489 Burner 1 170 905
12 HO7-660 Combustion chamber insulation 1 173 520
14 E67-492 Injector and housing - 24/30 1 170 908
HO7-770 Injector and housing - 35 1 173 522
16 E85-097 Fan assembly - 24/30 1 172 625
HO7-771 Fan assembly - 35 1 173 525
17 E69-286 Automatic air vent (Heat exchanger) 1 170 988
19 H58-082 Gas valve kit 1 174 789
23 H58-084 Thermistor (boiler control) 2 174 790
24 H58-086 Overheat thermostat 1 174 791
25 HO7-664 Ignition electrode kit 1 175 406
26 HO7-665 Flame detection electrode kit 1 173 529
32 H40-140 Kit - Trap and Seal 1 174 244
35 H49-851 itime user control programmer 1 174 487
36 H49-852 PCB primary controls kit (V9) 1 174 486
37 E67-519 Fuse PCB (3.15A L250V) 1 170 931
39 HO7-777 Mains switch c/w harness 1 173 537
40 HO7-731 Spark generator assy. 1 173 538
45 E67-527 Gasket kit (servicing) 1 170 938
52 E68-376 Seal kit (sealing panel) 1 171 014
53 E68-380 Turret gasket 1 171 022
61 H66-650 Pressure relief valve 1 175 413
62 H66-652 Expansion vessel 1 175 415
64 H69-341 Pressure gauge 1 170 991
65 H28-067 DHW thermistor 1 173 974
66 H58-165 Diverter valve motor head 1 174 813
67 H62-599 Diverter valve cartridge 1 175 411
69 H66-587 Pump Head 1 175 409
71 H66-588 Plate heat exchanger - 24 1 175 417
H66-589 Plate heat exchanger - 30 1 175 418
H66-592 Plate heat exchanger - 35 1 175 419
94 H66-644 Ignition lead 1 175 424
95 HO7-792 Detection lead 1 173 512
98 H58-225 Air vent (pump) 1 174 894
103 H29-018 Dry Fire Thermistor 1 174 087
Hardware Pack Contents (Ref. Frame 9):
Pack B - Accessory Pack 1 175 437
Pack C - Flow Valve Pack 1 175 431
Pack D - DHW Pack 24 1 175 434
30 1 175 435
35 1 175 436
Pack E - Gas Pack 1 175 433
Pack F - Return Valve Pack 1 175 432
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance specification
that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal.
(* Refer to boiler serial letter code on data plate to identify correct spare)
