Ideal Heating LOGIC HEAT2 H24 - User Manual

3User Guide
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com
where you can download the relevant information in PDF format.
USER GUIDE
October 2022
UIN 228298 A04
LOGIC HEAT
2
H12 H15 H18 H24 H30

Summary

1.2 Boiler Operation

TO START the boiler

Step-by-step guide for initiating the boiler's operation and setting initial parameters.

1.3 Frozen Condensate Drain

CONTROL OF WATER TEMPERATURE

Explains how to adjust water temperature based on sensor configuration.

To unblock a frozen condensate pipe

Instructions for safely thawing a frozen condensate pipe to restore boiler function.

1.6 Troubleshooting

NO HOT WATER

Troubleshooting steps for issues where the boiler is not providing hot water.

NO CENTRAL HEATING

Troubleshooting steps for issues where the boiler is not providing central heating.

1.7 Normal Operation Display Codes

Boiler is in Lockout for a specific error

Explains the display code indicating a lockout due to a specific error.

Boiler has a fault for a specific error

Details the display code signifying a fault condition requiring attention.

1.8 Fault Codes

Low Water Pressure

Details the action to take for the F01 fault code indicating low system water pressure.

Flame Loss

Provides actions for the F02 fault code related to flame detection issues.

Fan Fault

Outlines steps for addressing the F03 fault code indicating a fan malfunction.

Ideal Heating LOGIC HEAT2 H24 Specifications

General

Output Rating	24 kW
Fuel Type	Natural Gas
Mounting	Wall-mounted
CH Output (kW)	24 kW
Warranty	2 years
Dimensions (H x W x D)	700 mm x 395 mm x 278 mm
