Page 3
PERFORMANCE VERIFICAITONS
Perform the following analysis, if the meter conforms to the limits listed in Table 1 the meter is functioning
correctly. If the meter does not conform to any of the listed limits the calibration procedure must be
performed.
Performance Verification Preparation
1. Turn on the Calibrator, allow calibrator to warm up. Temperature Stabilization
should be reached after 30 minutes.
2. Remove battery cover and using a calibrated meter to ensure the battery measures a minimum of 7.5V
DC. If the battery measures under 7.5V DC, replace the battery before beginning the performance test.
3. Input the values listed in Table 1
Table 1 Performance Verification
Function Setting
Input
Low Limit
High Limit
ACV 200 190V AC@ 60Hz 187.7 192.3
ACV 500 400V AC@ 60Hz 392 408
DCV 2 1.900V DC 1.888 1.911
DCV 20 19.00V DC 18.88 19.11
DCV 200 190.0V DC 188.8 191.1
DCV 900 900V DC 893 906
DCmA 2m 1.900 mA DC 1.879 1.921
DCmA 20m 19.00 mA DC 18.79 19.21
DCmA 200m 190.0 mA DC 187.9 192.1
DC A 10 9.00 A DC 8.80 9.20
Ω 200
100.0 98.7 101.3
Ω 2K
1.000K .992 1.008
Ω 20K
10.00K 9.92 10.08
Ω 200K
100.0K 99.2 100.8
Ω 2M
1.000M .988 1.012
Form number TM61603 Rev 3 February 2002
