PERFORMANCE VERIFICATIONS
Perform the following analysis; if the meter conforms to the limits listed in Table 1 through 5 the meter is
functioning correctly. If the meter does not conform to any of the listed limits the calibration procedure
must be performed.
Performance Verification Preparation
1. Turn on the calibrator, allow calibrator to warm up. Temperature stabilization
should be reached after 30 minutes.
2. Remove battery cover and using a calibrated meter to ensure the battery measures a minimum of 7.5V
DC. If the battery measures under 7.5V DC, replace the battery before beginning the performance test.
3. Input the values listed in Table 1 through 5
Table 1 AC Voltage Test
Function
/Range
Input
Low
Limit
High
Limit
Model number
V AC 2000mV 1900mV AC @ 50Hz 1874 1926 61-702, 61-704
V AC 2000mV 1900mV AC @ 500Hz 1874 1926 61-702, 61-704
V AC 2000mV 1900mV AC @ 1kHz 1857 1943 61-702, 61-704
V AC 200V 190V AC @ 50Hz 187.4 192.6 61-700, 61-701, 61-702, 61-704
V AC 200V 190V AC @ 500Hz 187.4 192.6 61-700, 61-701, 61-702, 61-704
V AC 200V 190V AC @ 1kHz 185.7 194.3 61-700, 61-701, 61-702, 61-704
V AC 600V 500V AC @ 50Hz 485 515 61-700, 61-701
V AC 600V 500V AC @ 500Hz 485 515 61-700, 61-701
V AC 750V 700V AC @ 50Hz 681 719 61-702, 61-704
V AC 750V 700V AC @ 500Hz 681 719 61-702, 61-704
Table 2 DC Voltage Test
Function
/Range
Input
Low
Limit
High
Limit
Model number
V DC 200mV 190mV 188.9 191.1 61-700
V DC 2000mV 1900mV 1889 1911 61-700, 61-702, 61-704
V DC 20V 19V 18.89 19.11 61-701
V DC 200V 190V 188.9 191.1 61-700, 61-701, 61-702, 61-704
V DC 600V 500V 496 504 61-700, 61-701
V DC 1000V 900V 894 906 61-702, 61-704
Table 3 AC Current Test
Function
/Range
Input
Low
Limit
High
Limit
Model number
A AC 200A 100A AC @ 50Hz 96.5 103.5 61-700, 61-701, 61-702, 61-704
A AC 200A 100A AC @ 400Hz 94.5 105.5 61-700, 61-701, 61-702, 61-704
Form number TM61700-1-2-4 Rev 4 September 2004
