IDEAL 61-766 Technical Manual

Page 4
61-764
Function /
Range
Ranges Accuracy
660.0mV, 50Hz - 60Hz 1.7% + 8digits
6.600V/66.00V/660.0V, 50Hz - 100Hz 1.2% + 8 digits
6.600V/66.00V/660.0V, 100Hz - 400Hz 1.5% + 8 digits
AC Voltage
750V, 50Hz - 400Hz 1.5% + 8 digits
660.0mV 1.0% + 2 digits
DC Voltage
6.600V/66.00V/660.0V/1000V 0.5% + 2 digits
66.00A/660.0A, 50Hz - 60Hz 1.7% + 8 digits
AC Current
66.00A/660.0A, 60Hz - 400Hz 3.0% + 8 digits
660.0Ω/6.600KΩ/66.00KΩ/400.0KΩ
1.0% + 4 digits
4.000MΩ
5.0% + 4 digits
Resistance
10.00MΩ
12.0% + 5 digits
Continuity
<40Ω on
Continuity
Not Specified
61-766
Function /
Range
Ranges Accuracy
660.0mV, 50Hz - 60Hz 1.7% + 8 digits
6.600V/66.00V/660.0V, 50Hz - 100Hz 1.2% + 8 digits
6.600V/66.00V/660.0V, 100Hz - 400Hz 1.5% + 8 digits
AC Voltage
(True RMS)
750V, 50Hz - 400Hz 1.5% + 8 digits
660.0mV 1.0% + 2 digits
DC Voltage
6.600V/66.00V/660.0V/1000V 0.5% + 2 digits
66.00A/660.0A, 50Hz - 60Hz 1.7% + 10 digits AC Current
(True RMS)
66.00A/660.0A, 60Hz - 400Hz 3.0% + 10 digits
Capacitance 6.600µ/66.00µ/660.0µ F 3.0% + 10 digits
Frequency 20Hz ~ 400Hz (Auto-ranging) 0.1% + 3 digits
660.0Ω/6.600KΩ/66.00KΩ/400.0KΩ
1.0% + 4 digits
4.000MΩ
5.0% + 4 digits
Resistance
10.00MΩ
12.0% + 5 digits
Continuity
<40Ω on
Continuity
Not specified
61-768
Function /
Range
Ranges Accuracy
660.0mV, 50Hz - 60Hz 1.7% + 8 digits
6.600V/66.00V/660.0V, 50Hz - 100Hz 1.2% + 8 digits
6.600V/66.00V/660.0V, 100Hz - 400Hz 1.5% + 8 digits
AC Voltage
(True RMS)
750V, 50Hz - 400Hz 1.5% + 8 digits
660.0mV 1.0% + 2 digits
DC Voltage
6.600V/66.00V/660.0V/1000V 0.5% + 2 digits
660.0A, 50Hz - 60Hz 2.0% + 10 digits AC Current
(True RMS)
660.0A, 60Hz - 400Hz 3.0% + 10 digits
DC Current 660.0A 2.0% + 5 digits
660.0Ω/6.600KΩ/66.00KΩ/400.0KΩ
1.0% + 4 digits
4.000MΩ
5.0% + 4 digits
Resistance
10.00MΩ
12.0% + 5 digits
Continuity
<40Ω on
Continuity
Not specified
Form number TM61764-6-8 Rev 5 November 2007
