EXALT Solo 155 Internal Components

4

5

6

6

7

1

3

8

2

Item Part #Description

1EXARKIT40 Vent Outlet/Combustion Air Inlet Adapter

2EXARKIT02 Heat Exchanger Body

3EXARKIT56 CH Supply Temperature Sensor

4EXARKIT59 Low Water Cut O

5EXARKIT56 CH Return Temperature Sensor

6EXARKIT85 Condensate Drain Assembly

7EXARKIT41 Flue Tube

8EXARKIT57 Flue Temperature Sensor
