Fig. 47 - EXALT Combi Hydro-block

CHAPTER 18

CHAPTER 18 - REPLACEMENT PARTS

Item Part # Description

EXRKIT60 Hydroblock

EXRKIT61 Valve Motor

EXRKIT62 3 Way Valve

EXRKIT58 Flow Sensor

5 EXRKIT69 Combi supply fittings (CH & DHW)

6 EXRKIT71 Combi DWH inlet fitting

7 EXRKIT72 Combi CH return

8 EXRKIT56 Domestic Water Temperature Sensor
