1. INTRODUCTION
The Logic Air Heat Pump System consists of the following key
components.
• Logic Air Monobloc Air Source Heat Pump (installed external
to the property).
• Logic Air Domestic Hot Water Cylinder
• L ogic Air Control Box (Supplied separately as a wall mounted
option or as part of the Logic Air Pre-Plumbed option).
The Logic Air Monobloc Heat Pump is an Air to Water type
system and suitable to be installed in a domestic household
within a closed loop heating system. The Logic Air Monobloc
Heat Pump does not provide a cooling function. The appliance
will produce condensate water, a suitable disposal system and
drainage point shall need to be installed.
The Heat Pump takes heat from the ambient outdoor air for
transfer into domestic hot water or space heating system. This
air is not to be ducted or re utilised and must be allowed to ow
freely back into the natural environment.
The Logic Air Domestic Hot Water cylinder is to be used to store
heat from the Heat Pump. The DHW cylinder is to be installed
within a domestic household.
The Logic Air Control Box provides the overall interface and
control of the heating entire system. The control box is to be
installed within the property, a limited interface is provided for the
end user, however a programmable room thermostat will provide
the day to day interface such as space heating temperatures and
schedule / timer functions.
2. SAFETY
Flammable Refrigerant:
The Heat Pump is charged with R32 which is a ammable,
odourless, and colourless refrigerant. In the event of a leak from
the refrigerant circuit this can create a hazardous environment.
To reduce the risk of a hazardous event, the installation
instructions should be followed, and the installation area should
be kept clear of ignition sources, including but not limited to;
electrical switches, electrical plug sockets, and lamps.
Modication of the Products and Installation Environment:
The product is not to be modied or tampered with in any way
that is not dened and approved by this document. Make sure
that the requirements for both the products and installation
environments are always followed. The end user should
be properly informed of the installation area and product
requirements during the handover process.
Improper Maintenance:
The product is to be regularly maintained and serviced by an
appropriately qualied service engineer. The end user should be
properly informed of maintenance and care requirements during
the handover process.
Inappropriate Operation:
The product is to be operated as outlined in both this document
and the user manuals. The end user must be properly informed
of intended and acceptable operation methods during the
handover process.
Electrical Risk:
Work on electrical components must only be carried out by a
competent electrician. Electrical supplies must be locked in the
o󰀨 position when any work is done near electrical components.
Failure to comply with this requirement can result in severe injury
or death. If any of the supply cables are damaged, they must
be replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
Correct Disposal of Waste:
Waste from the products, such as cardboard, plastics, and
refrigerant must be disposed of appropriately and recycled
where applicable. Refrigerant must not be released into the
atmosphere.
Presence of Frozen Condensate in Walkways:
There is condensate produced by the Heat Pump which can
potentially build up around the heat pump and freeze if not
properly disposed of. Appropriate disposal methods of the
condensate should be implemented and maintained to prevent
slipping hazard.
Electrical Safety
Electrical Supply.
Power Supply – 230 V ~ 50Hz
4 & 5 kW Recommended Circuit Breaker size 16A.
8 & 10 kW Model Recommend Circuit Breaker size 32A.
This appliance is to be earthed.
The system is provided with two separate 230V power supplies;
one is for the Logic Air Monobloc Heat Pump and shared with the
Logic Air Control Box. The second power supply is intended for
the backup up heater.
ⓘ IMPORTANT: This appliance must not be operated
without all the covers and casing(s) correctly tted.
If it is known or suspected that a fault exists on the
system, then it MUST NOT BE USED until the fault has
been investigated and corrected by a suitably trained and
competent person.
Under NO circumstances should any sealed components on
this appliance be used incorrectly or tampered with.
This appliance can be used by children 8 years and above. Also,
persons with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, provided they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
