35
INSTALLATION
Solar Thermal - Installation and Servicing
30
OVERVIEW OF MATERIALS - FLAT ROOF KIT (TS8000)
Bench screw M12*350 Rubber seal M12 washer
M12 hex nut
Clamping piece Clamping piece extension
Mounting part, top Mounting part extension
M8 washer
M8*30 hex bolt M8*30 hammer-head bolt M8 hex nut
Attachment bracket Base bracket Support bracket
Support rail
Mounting jig Flat gasket
INSTALLATION
207786-2.indd 35 16/02/2012 11:26:14
