OVERVIEW OF MATERIALS - IN ROOF (TS8001)
Installation batten 30x40x2450 Attachment bracket Self-trapping screws 5*60 / 5*40
Flat gasket
Front corner section right/left or middle
Connecting bend
Side piece right/left Side tin cover strip
Sealed plumping screw 4,5*35
Middle cover strip Sealed plumping screw 3,9*13 Wooden wedge
Self-trapping screws 6*120 Side piece connector right/left Middle cover right/left or middle
Rear corner section right/left or middle
Self-trapping screws 4*25 Metal retainer, roofing nail
Foam rubber wedge
