INSTALLATION
Solar Thermal - Installation and Servicing
7
OVERVIEW OF MATERIALS - ON ROOF
Roof bracket Roof bracket console Self-tapping screws 6*60
Cup square bolt 8*25 M8 hex self-securing nut Clamping piece
Clamping piece extension Mounting part, top Mounting part extension
M8 washer M8*30 hammer-head bolt M8 hex nut
Support rail Mounting jig Flat gasket
