Viceroy GT Range - Installation 21
ASSEMBLY
Data notes
Fuel rates and flue gas data relates to maximum outputs ratings
Gas firing data relates to the use of NATURAL GAS ONLY
Details for the use of LPG are available, on request, to Caradon Ideal Ltd
The gas rate at calorific values differing from the standard quoted above may be calculated by direct proportion
CALORIFIC VALUE; 38.5 MJ/m
3
(1035 btu/ft
3
)
Boiler Size 8 9 10 11 12 13 14
Maximum Heat Output kW 390 450 540 600 670 720 780
Btu/h x 10
3
1,330 1,535 1,842 2,047 2,286 2,456 2,661
Minimum Heat Output kW 300 390 450 540 600 670 720
Btu/h x 10
3
1,024 1,330 1,535 1,842 2,047 2,286 2,456
Combustion Chamber Volume m
3
0.31 0.35 0.39 0.44 0.48 0.52 0.57
ft
3
10.9 12.5 13.9 15.5 16.9 18.5 19.9
Flue Way Content m
3
0.56 0.64 0.71 0.78 0.86 0.93 1.01
ft
3
19.8 22.5 25.1 27.8 30.4 32.9 35.6
Boiler Water Content l 366 409 452 495 538 581 624
gal 80.5 89.9 99.4 109 118.4 127.8 137.3
Hydraulic Resistance at 15k mbar 17 26.5 40.8 45.3 56.4 68.8 86.8
in.w.g. 6.8 10.6 16.3 18.1 22.5 27.5 34.7
Combustion Chamber Resistance mbar 1.1 1.5 2 2.5 2.5 2.5 3.5
in.w.g. 0.44 0.6 0.8 1 1 1 1.4
Boiler DRY weight less burner unit kg 1,470 1,650 1,830 2,010 2,190 2,370 2,550
lb 3,240 3,637 4,034 4,431 4,828 5,225 5,622
General Data
Boiler Size 8 9 10 11 12 13 14
Minimum Oil Rate l/h 39.71 45.85 55.02 61.13 68.26 73.36 79.47
gal/h 8.73 10.08 12.1 13.45 15.02 16.14 17.5
Maximum Flue Gas Volume l/sec 247.3 285.5 342.6 380.8 425.2 456.8 495.5
ft
3
/min 524 605 726 807 901 968 1,050
Oil Firing Data
Boiler Size 8 9 10 11 12 13 14
Minimum Gasl Rate m
3
/h 40.5 46.7 56.1 62.3 69.6 74.8 81
ft
3
/h 1,430 1,649 1,981 2,199 2,457 2,641 2,860
Maximum Flue Gas Volume m
3
/sec 0.24 0.28 0.33 0.37 0.41 0.45 0.48
ft
3
/min 8.47 9.88 11.65 13.06 14.47 15.8 16.9
Gas Firing Data
