28: AS-INTERFACE MASTER COMMUNICATION
28-40 « FC4A MICROSMART USER’S MANUAL »
HW Series (continued)
Note: Three-position selector, key selector, and illuminated selector switches use two communication blocks, therefore require two slave addresses. For the
communication block mounting position, see page 28-36.
Slave Number
Selector, Key selector:
3-position
Illuminated selector: 2-position Illuminated selector: 3-position
Input DI2 (Comm. Block ➀ ➁) Input DI2 Output DO0 Input DI2 (Comm. Block ➀ ➁) Output DO0 (Comm. Block ➁)
(Slave 0) M1302 M1302 M1620 M1302 M1620
Slave 1(A) M1306 M1306 M1624 M1306 M1624
Slave 2(A) M1312 M1312 M1630 M1312 M1630
Slave 3(A) M1316 M1316 M1634 M1316 M1634
Slave 4(A) M1322 M1322 M1640 M1322 M1640
Slave 5(A) M1326 M1326 M1644 M1326 M1644
Slave 6(A) M1332 M1332 M1650 M1332 M1650
Slave 7(A) M1336 M1336 M1654 M1336 M1654
Slave 8(A) M1342 M1342 M1660 M1342 M1660
Slave 9(A) M1346 M1346 M1664 M1346 M1664
Slave 10(A) M1352 M1352 M1670 M1352 M1670
Slave 11(A) M1356 M1356 M1674 M1356 M1674
Slave 12(A) M1362 M1362 M1680 M1362 M1680
Slave 13(A) M1366 M1366 M1684 M1366 M1684
Slave 14(A) M1372 M1372 M1690 M1372 M1690
Slave 15(A) M1376 M1376 M1694 M1376 M1694
Slave 16(A) M1382 M1382 M1700 M1382 M1700
Slave 17(A) M1386 M1386 M1704 M1386 M1704
Slave 18(A) M1392 M1392 M1710 M1392 M1710
Slave 19(A) M1396 M1396 M1714 M1396 M1714
Slave 20(A) M1402 M1402 M1720 M1402 M1720
Slave 21(A) M1406 M1406 M1724 M1406 M1724
Slave 22(A) M1412 M1412 M1730 M1412 M1730
Slave 23(A) M1416 M1416 M1734 M1416 M1734
Slave 24(A) M1422 M1422 M1740 M1422 M1740
Slave 25(A) M1426 M1426 M1744 M1426 M1744
Slave 26(A) M1432 M1432 M1750 M1432 M1750
Slave 27(A) M1436 M1436 M1754 M1436 M1754
Slave 28(A) M1442 M1442 M1760 M1442 M1760
Slave 29(A) M1446 M1446 M1764 M1446 M1764
Slave 30(A) M1452 M1452 M1770 M1452 M1770
Slave 31(A) M1456 M1456 M1774 M1456 M1774
Slave 1B M1466 M1466 M1784 M1466 M1784
Slave 2B M1472 M1472 M1790 M1472 M1790
Slave 3B M1476 M1476 M1794 M1476 M1794
Slave 4B M1482 M1482 M1800 M1482 M1800
Slave 5B M1486 M1486 M1804 M1486 M1804
Slave 6B M1492 M1492 M1810 M1492 M1810
Slave 7B M1496 M1496 M1814 M1496 M1814
Slave 8B M1502 M1502 M1820 M1502 M1820
Slave 9B M1506 M1506 M1824 M1506 M1824
Slave 10B M1512 M1512 M1830 M1512 M1830
Slave 11B M1516 M1516 M1834 M1516 M1834
Slave 12B M1522 M1522 M1840 M1522 M1840
Slave 13B M1526 M1526 M1844 M1526 M1844
Slave 14B M1532 M1532 M1850 M1532 M1850
Slave 15B M1536 M1536 M1854 M1536 M1854
Slave 16B M1542 M1542 M1860 M1542 M1860
Slave 17B M1546 M1546 M1864 M1546 M1864
Slave 18B M1552 M1552 M1870 M1552 M1870
Slave 19B M1556 M1556 M1874 M1556 M1874
Slave 20B M1562 M1562 M1880 M1562 M1880
Slave 21B M1566 M1566 M1884 M1566 M1884
Slave 22B M1572 M1572 M1890 M1572 M1890
Slave 23B M1576 M1576 M1894 M1576 M1894
Slave 24B M1582 M1582 M1900 M1582 M1900
Slave 25B M1586 M1586 M1904 M1586 M1904
Slave 26B M1592 M1592 M1910 M1592 M1910
Slave 27B M1596 M1596 M1914 M1596 M1914
Slave 28B M1602 M1602 M1920 M1602 M1920
Slave 29B M1606 M1606 M1924 M1606 M1924
Slave 30B M1612 M1612 M1930 M1612 M1930
Slave 31B M1616 M1616 M1934 M1616 M1934
