APPENDIX
A-10 « FC4A MICROSMART USER’S MANUAL »
Cables
Name Function Type No.
Modem Cable 1C
(3m/9.84 ft. long)
Used to connect a modem to the MicroSmart RS232C port, with D-
sub 25-pin male connector to connect to modem
FC2A-KM1C
Computer Link Cable 4C
(3m/9.84 ft. long)
Used to connect a computer to the MicroSmart RS232C port (1:1
computer link), with D-sub 9-pin female connector to connect to
computer
FC2A-KC4C
User Communication Cable 1C
(2.4m/7.87 ft. long)
Used to connect RS232C equipment to the MicroSmart RS232C
port, without a connector to connect to RS232C equipment
FC2A-KP1C
O/I Communication Cable 1C
(5m/16.4 ft. long)
RS232C cable used to connect IDEC HG1B/2A/2C operator inter-
face to MicroSmart RS232C port 1 or 2
FC4A-KC1C
O/I Communication Cable 2C
(5m/16.4 ft. long)
RS232C cable used to connect IDEC HG2F operator interface to
MicroSmart RS232C port 1 or 2
FC4A-KC2C
Analog Voltage Input Cable
(1m/3.28 ft. long)
Used to connect an analog voltage source to the analog voltage
input connector on the slim type CPU module (package quantity 2)
FC4A-
PMAC2PN02
Shielded CPU Flat Cable
(0.5m/1.64 ft. long)
26-wire shielded straight cable for connecting the MicroSmart slim
type CPU module to an I/O terminal
FC9Z-H050A26
Shielded CPU Flat Cable
(1m/3.28 ft. long)
FC9Z-H100A26
Shielded CPU Flat Cable
(2m/6.56 ft. long)
FC9Z-H200A26
Shielded CPU Flat Cable
(3m/9.84 ft. long)
FC9Z-H300A26
Non-shielded CPU Flat Cable
(0.5m/1.64 ft. long)
26-wire non-shielded straight cable for connecting the MicroSmart
slim type CPU module to an I/O terminal
FC9Z-H050B26
Non-shielded CPU Flat Cable
(1m/3.28 ft. long)
FC9Z-H100B26
Non-shielded CPU Flat Cable
(2m/6.56 ft. long)
FC9Z-H200B26
Non-shielded CPU Flat Cable
(3m/9.84 ft. long)
FC9Z-H300B26
Shielded I/O Flat Cable
(0.5m/1.64 ft. long)
20-wire shielded straight cable for connecting the MicroSmart I/O
module to an I/O terminal
FC9Z-H050A20
Shielded I/O Flat Cable
(1m/3.28 ft. long)
FC9Z-H100A20
Shielded I/O Flat Cable
(2m/6.56 ft. long)
FC9Z-H200A20
Shielded I/O Flat Cable
(3m/9.84 ft. long)
FC9Z-H300A20
Non-shielded I/O Flat Cable
(0.5m/1.64 ft. long)
20-wire non-shielded straight cable for connecting the MicroSmart
I/O module to an I/O terminal
FC9Z-H050B20
Non-shielded I/O Flat Cable
(1m/3.28 ft. long)
FC9Z-H100B20
Non-shielded I/O Flat Cable
(2m/6.56 ft. long)
FC9Z-H200B20
Non-shielded I/O Flat Cable
(3m/9.84 ft. long)
FC9Z-H300B20
