« FC4A MICROSMART USER’S MANUAL » iii
INDEX
read prohibit flag M8015 6-11
write flag M8020 6-11
write/adjust error flag M8013 6-11
setting using
a user program
15-5
WindLDR 15-5
carry
(Cy) and borrow (Bw) M8003
6-10
or borrow signals 11-2
cartridge 30-8
clock 2-67
memory 2-64
catch input 5-18
ON/OFF status M8154-M8157 6-13
CC= and CC≥ instructions 7-14
CDI 28-26
Celsius 24-12
change
counter preset and current values
7-10
timer preset and current values 7-8
changing
analog output
24-21
calendar data 5-40
clock data 5-41
data register values 5-37
preset values for timers and counters 7-13
timer/counter preset values 5-35
changing ID1 code of slave 0 28-27
character string 5-43
clear button 7-13
clearing
changed preset values
7-13
error
codes
29-2
data 5-39
high-speed counter current value 5-10
clock
adjusting using a user program
15-6
cartridge 2-5, 2-15, 2-67
adjusting accuracy 15-7
backup duration 15-7
enable adjustment 15-7
data 5-41
adjust flag M8021 6-11
write flag M8017 6-11
function processing 30-2
IC error 29-5
CMP< 10-1
CMP<= 10-1
CMP<> 10-1
CMP= 10-1
CMP> 10-1
CMP>= 10-1
CNT, CDP, and CUD instructions 7-10
communication
adapter information D8030
6-17
adapters 2-61
block mounting position 28-36
completion relay M8080 25-6
connector cover removing 3-6
distance 1-8
function 2-5, 2-15
mode information D8026 6-17
modules 2-61
parameters 17-5, 17-33, 17-34, 26-2, 27-10
settings 26-3
tab 17-5, 25-7, 25-8, 26-2, 27-10
compare
equal to
10-1
greater than 10-1
greater than or equal to 10-1
less than 10-1
less than or equal to 10-1
unequal to 10-1
comparison
output
5-11, 5-12
result
equal to M8151
6-13
greater than M8150 6-13
less than M8152 6-13
M8150, M8151, M8152 10-2, 10-4
computer link
1:1 communication
1-5
1:N communication 1-5
cable 4C 4-1, 28-6, 30-4
communication 26-1
system 1-5
Config_OK 28-23
Configuration 28-24
configuration 28-32
data image (CDI) 28-26
mode 28-15
configure AS-Interface master 28-30
configuring a slave 28-10
confirm
button
5-29, 7-13
password 5-26
confirming changed
preset values
7-13
timer/counter preset values 5-36
Connected Mode 28-24
connected mode 28-15
connector pinout 17-3, 17-32, 27-1, 30-4, 30-5, 30-6
constant scan time 5-27
contact protection circuit for output 3-15
control
register
20-2, 20-7, 20-13, 20-24, 21-3
relay 21-11
control signal
option
DSR D8105
17-30
DTR D8106 17-30
status D8104 17-29
conversion 16-1, 16-3
linear 19-5
type 17-8, 17-17
convert
X to Y
19-2
Y to X 19-3
coordinate conversion instructions 19-1
counter
adding (up) counter
7-10
and shift register in master control circuit 7-24
comparison instructions 7-14
