IDEC SmartRelay functions
IDEC SmartRelay Manual 229
Setting the Par parameter
The following illustration shows the view in programming
mode that corresponds to the first example (12 + (6 / 3)) - 1:
B1 1+/
V1=+00012
OP1= +
PR1=M
B1 4+/
V4=+00001
Qen
0: 0
p=0
B1 2+/
V2=+0006
OP2=/
PR2=H
B1 3+/
V3=+00003
OP3=–
PR3=L
Use the and keys to navigate between the operand
value, operator, and operation priority. To change a value,
use the
and keys to scroll through value choices for
each value. Use the
key to navigate from one screen to the
previous screen when the cursor is on the V1..V4 line, and
the
key to navigate to the next screen from the PR1..PR3
line. Use the OK key to accept changes.
