4. MSO3xx
4.1 Physical Characteristics
The MSO3xx/3xx1 are dedicated to be connected to an USB port, which supplies the
required power.
Figure 1: MSO300 3D View
4.1.1 Dimensions and Weight
Device
Dimensions (L x w x h)
Weight*
Sensor
MSO3xx
80 x 92 x 57 mm
300 g
416 x 416
pixels
Table 2: MSO 300 devices, weight and sizes
*The weight doesn’t include the cord.
4.1.2 Temperature range and humidity
Device
Temperature range
Humidity
Operating
Storage
Operating
Storage
MSO3xx
0°C to 50°C
- 20°C to 70°C
10% < RH < 80%
non-condensing
RH < 95%
Table 3: MSO 300 devices, temperature and humidity range
4.1.3 IP rating
Device
IP rating
