MSO Fingerprint scanners Installation Guide
Error! Use the Home tab to apply Titre 1 to the text that you want to appear here.
This document and the information therein are the property of IDEMIA. They must not be copied
or communicated to a third party without the prior authorization of IDEMIA
Table 4: MSO 300 devices, IP rating
The table above defines also the maximum value of the IP (ingress protection) rating which
can be reached by a product which integrate (according to the appropriate
recommendations) an OEM model.
4.2 General description
4.2.1 Top view
Figure 2: MSO3xx Top View
4.2.2 Bottom view
Figure 3: MSO3xx Bottom View
