5. MSO1300
5.1 Physical Characteristics
The MSO1300 device is dedicated to be connected to an USB port, which supplies the
required power.
Figure 4: MSO1300
5.1.1 Dimensions and Weight
Device
Dimensions (L x w x h)
Weight*
Sensor
MSO1300
68,7 x 39,7 x 15,3 mm
40 g
400 x 256
pixels
Table 5: MSO 1300 devices, weight and sizes
*The weight doesn’t include the cord.
5.1.2 Temperature range and humidity
Device
Temperature range
Humidity
Operating
Storage
Operating
Storage
MSO1300
0°C to 50°C
- 20°C to 70°C
10% < RH < 85%
RH < 95%
Table 6: MSO 1300 devices, temperature and humidity range
5.1.3 IP rating
Device
IP rating
