8.2 MSO13x0 Man Machine Interface
8.2.1 Description
This section applies to MSO1300 and to MSO1350 devices which have none additional LED:
the Man Machine Interface is reduced to the sensor light on/off.
8.2.2 Biometric terminal status
Status
Sensor
Suspend (low power mode)
Off
Stand By (wait for a request from host system)
Off
Maintenance State (such as firmware update in
progress)
Blinking
Personalization State (secure MSO)
Blinking
Unrecoverable Error or USB enumeration Error
Off
Table 16: MSO13x0 system status
8.2.3 Biometric request status
Status
Sensor
Waiting For Finger
On
Waiting For Finger Removal
On
Finger Misplaced Or Latent
On
Switch To Next Finger (enroll process)
On
Recognized Finger
Off
Finger Unknown / Failure
Off
Table 17: MSO13x0 biometric process status
8.2.4 Smart card reader status (MSO1350)
Status
Sensor
Smart Card powered on
One blink
Smart Card powered off
No signal
Smart Card treatment in progress
No signal
Table 18: MSO1350 smart card request status
