3.3
Maintenance
3.3.1 General safety instructions for maintenance
WARNING
Check the MSDS of the colorants about
personal protection measures required for
handling the colorant.
CAUTION
Do not use cleaning agents based on organic
solvents to clean the machine.
3.3.2 General cleaning: after every operation
1. Clean the machine with a cloth and remove all spilled paint or
other liquid.
3.3.3 Periodic maintenance: weekly
1. Remove all spilled paint from the machine. Refer to § 3.4.
2. Grease the A. Guide bars B. Spline shaft C. Lead Screw
D. Bevel gear E. Pinion gear.
Recommend to use thick grease like SKF VKG 9/0.5
3.3.4 Periodic maintenance: monthly
1. Remove all spilled paint from the machine. Refer to § 3.4.
2. Remove all dirty grease from the machine.
3. Add new grease.
4. Grease the axle and other sliding parts.
3.4
Remove spilled paint
Do this procedure when paint is spilled inside the machine.
1.
Make sure that the machine is stopped. See § 3.2.11.
2.
Put a reservoir (A) below the drain orifice (B).
CAUTION
Make sure that the reservoir is big enough to
hold all the spilled paint.
3.
Remove the Cover (C). The spilled paint comes out of the
machine.
4.
Dispose of the spilled paint according to local regulations.
5.
Install the cap to the drain orifice.
6.
Clean the machine. See § 3.3.
