4.1.3 Remove the transport brackets
1. Remove the screws (A).
2. Remove the transport brackets (B).
4.2
Put the machine in position
4.2.1 Put the machine in position
1. Loosen the nuts (C) of the adjustable feet(B).
2. Move up the adjustable feet until the wheels (A)
are on the round.
3. Tighten the nuts to lock the feet.
4. Move the machine to end stop beam.
