10
DOC No: 8540 REV D
Pumping ammable uids without a proper earthing connection may
cause spontaneous ignition.
EagleDrive Electrical Connection
Ensure that the pump motor is earthed. The pump may be electrically
isolated from the motor depending on the mounting conguration. Some
installations may need an earthing connection on the pump head.
Before starting any electrical installation work ensure that the main
electrical supply is adequately isolated.
Electrical installation must be carried out by qualied personnel who are
conversant with local electricity installation regulations.
Ensure that the voltage of the supply is correct for the motor being
connected, and that the source is Class 2 or a Limited Power Source.
Ensure that all electrical connections use a common earth ground to
avoid hazardous ground loops.
Ensure that only power supplies having SELV specication are
connected to the EagleDrive.
Ensure that all associated equipment has a form of overcurrent
protection. If a fuse is used see table below for recommendations.
Power In
The main input power is 12 to 36 VDC from a Class 2 (SELV) source applied across the
power in and common ground leads. This voltage must be maintained within the specied
limits as the motor is loaded to its maximum current of 2A (Model - MS) or 3A (Model -
EL.)
Ensure that the power supply voltage ripple is maintained below 5% peak
to peak.
EaglEDrivE MoDEl rEcoMMEnDED fusE
Ms littlEfusE 0313002 HXP
El littlEfusE 0313003 HXP
