Idex MICROPUMP EagleDrive MS User Manual

5
DOC No: 8540 REV D
The following are used throughout this guide to indicate procedure that, if not followed
correctly, may result in injury to personnel or damage to equipment.
Warnings are used to alert the reader to a procedure or practice, which if
not followed correctly, could result in personal injury.
Limits of Use 6
Installation in Explosive and Fire Danger Zones 7
Description 7
Function 7
Unpacking and Storage 8
Assembly 8
Space Requirements 8
Location 9
Bulkhead Mounting 9
EMC Compatibility 9
Electrical Connection 10
Lead Assignments 12
Operation 13
Manual Control Adjustment 14
Magnet Decoupling 15
Maintenance 15
Fault Isolation 16
Technical Specication 17-19
Notes 20-22
Table of Contents
CAUTION
NOTE
Warning - Hot Surface is used to alert the reader to a procedure or
practice, which if not followed correctly, could result in personal injury
due to contact with a hot surface.
Cautions are used to alert the reader to a procedure or practice, which
if not followed correctly, could result in damage to the pump, motor, or
ancillary equipment.
Notes are used to highlight important information that may assist the reader in
carrying out a procedure or in understanding the text.
