IDS 816 - 3 Understanding the Keypad Indicators

IDS816 User Manual 700-283-01H Issued January 2009
8
3.
3. 3.
3. Understanding the Keypad Indicators
Understanding the Keypad IndicatorsUnderstanding the Keypad Indicators
Understanding the Keypad Indicators
Refer to the labelled pictures of the keypads.
1. ARMED Indicator (Red)
On System Armed
Off System Disarmed
Flashing
Alarm Condition
(Check Alarm Memory zone details BEFORE re-arming)
2. AWAY Indicator (Red)
On System Armed in Away Mode
Off System Disarmed / Armed in Stay Mode
Flashing User Programming (Chime/Buzz/Stay zones)
3. POWER Indicator (Red)
On Mains Power is Present
Flashing Trouble Condition
4. READY Indicator (Green)
On System is Ready to be Armed
5. ZONE Indicators (Yellow)
On Zone Bypassed
Off Zone Clear
Flashing Zone Violated or Tampered
