IDS NXT: Setup IDS NXT rio
Power supply
NOTICE! The camera can be supplied with voltage both from an external source and via
Power-over-Ethernet (PoE). The camera should not be supplied through both voltage sources
at once as this can irreparably damage the camera.
Input I/O connector (M12): 12-24 V DC +20 %
Input GigE connector (RJ45): PoE 41-57 V DC
Input I/O connector (M12): min. 1 A
Input GigE connector (RJ45): min. 350 mA
IDS Imaging Development Systems GmbH recommends to adjust the power supply to the power requirement
of the camera to limit overheating in case of short circuit.
To ensure the electrical safety, the camera power supply must meet the requirements for SELV (safety extra
low voltage) / LPS (limited power source) or ES1 / PS2. The camera power supply must be rated by the values
given in the table above. It also must ensure that the voltage values given in the table above are available at the
input of the camera.
Avis pour le Canada:
IDS Imaging Development Systems GmbH recommande d'adapter l'alimentation électrique aux besoins de
la caméra afin de limiter la surchauffe en cas de court-circuit.
Pour garantir la sécurité électrique, l'alimentation de la caméra doit être conforme aux exigences de
sécurité SELV (très basse tension de sécurité)/LPS (source à puissance limitée) ou ES1/PS2.
L'alimentation de la caméra doit respecter les valeurs indiquées dans le tableau ci-dessus. Elle doit
également répondre au fait que les tensions indiquées dans le tableau ci-dessus sont présentes à l'entrée
de la caméra.
Information on the power consumption of individual camera models can be found in the model data sheet.
Keep in mind that a voltage drop will occur when you use long cables for power supply to the
camera. Choose the size of the cable in such a way that the supply voltage available at the
input of the camera is at least 12 V.
To supply the IDS NXT rio camera with power using PoE or PoE+, you can use PoE
injectors or switches that are compatible with IEEE standard 802.3af or IEEE standard
802.at.
