INSTALLATION,OPERATION,&MAINTENANCEMANUAL
16
SECTIONFOUR–EquipmentStart-up
IMPORTANT
Fancoilunitsmustbelledwithwaterbeforeoperatingthecirculator.Thecirculatorbearingsarewater
lubricatedandshouldnotbeallowedtooperatedry.Fillingthesystemproperlywillresultinimmediate
lubricationofthebearings.
ReceivingandInspection
 Unitreceivedundamaged
 Unitreceivedcompleteasordered
 “Furnishonly”partsaccountedfor
 Unitarrangement/handcorrect
 Unitstructuralsupportcompleteandcorrect
HandlingandInstallation
 Mountinggrommets/isolatorsused
 Unitmountedlevelandsquare
 Properaccessprovidedforunitandaccessories
 Properelectricalserviceprovided
 Properover-currentprotectionprovided
 Properserviceswitch/disconnectprovided
 Properchilledwaterlinesizetounit
 Properhotwaterlinesizetounit
 Allservicestounitincodecompliance
 Allshippingscrewsandbracesremoved
 Unitprotectedfromdirtandforeignmatter
Cooling/HeatingConnections
 Protectvalvepackagecomponentsfromheat
 Mountvalvepackages
 Connecteldpipingtounit
 Pressuretestallpipingforleaks
 Installdrainlineandtraps,asrequired
 Insulateallpiping,asrequired
 Installdriplipunderpiping,asrequired
DuctworkConnections
 Installductwork,ttingsandgrilles,asrequired
 Flexibleductconnectionsatunit
 Propersupplyandreturngrilletypeandsize
 Controloutsideairforfreezeprotection
 Insulateallductwork,asrequired
ElectricalConditions
 Refertounitwiringdiagram
 Connectincomingpowerserviceorservices
 Installandconnect“furnishonly”parts
UnitStart-up
 Generalvisualunitandsysteminspection
 Checkforproperfanrotation
 Recordelectricalsupplyvoltage
 Checkallwiringforsecureconnections
 Closeallunitisolationvalves
 Flushwatersystems
CheckList
