ifm Device Manual IO-Link Master with PROFINET interface CabinetLine 8 Ports IP 20 (AL1900) 05 / 2018
Configuration PROFINET
8.2.5 Configure the PROFINET port
22761
In order to configure the Ethernet interface of the AL1900:
Prerequisites
> AL1900 is correctly integrated in the PROFINET project (→ Add the IO-Link master to the PROFINET network
(→ p. 36)).
1 Open object characteristics
► Start the application "HW Config"
► Click on AL1900.
► Select [Target System] > [Ethernet ...] > [Edit Ethernet Users].
> [Edit Ethernet Users] window appears.
2 Search AL1900
► Click on [Browse ...] button.
> [Browse Network] window appears.
► Click on [Start] button.
> STEP 7 browses the PROFINET network for devices.
> List shows found devices.
► Select AL1900 in list and click [OK] to adopt the device.
> The [MAC address] shows the MAC address of the AL1900
3 Set IP address and network mask
► Click on the [Use IP parameters] selection field in group [Set IP configuration].
► Enter the required IP address in the [IP address] field.
► Enter the required subnet mask in the [Subnet mask] field.
4 Assign device names
► Enter the required PROFINET name in the [Device name] field.
► Click on the [Assign Name] button.
> STEP 7 assigns the selected name to the AL1900.
► Click on the [Close] button to close the window.
>
8.2.6 Configure IO-Link devices
18428
The AL1900 supports the configuration of the connected IO-Link devices out of the PROFINET
projection software. The configurable parameters depend on the corresponding IO-Link device.
Information about the usable functions: → PROFINET: Programmers' notes (→ p. 42)
Available parameters of the IO-Link devices: → Operating instructions of the IO-Link device
