ifm Device Manual IO-Link Master with PROFINET interface CabinetLine 8 Ports IP 20 (AL1900) 05 / 2018
Appendix Technical data
>
13.1.10 Electrical connection
11030
Voltage supply IN X31
Plug and socket connection
COMBICON
Wiring
1:
GND (US)
2:
GND (US)
3:
+ 24 V DC (US)
4:
+ 24 V DC (US)
Process connection IO-Link ports Class A X01...X0<IOL_AnzPorts>
Plug and socket connection
COMBICON
Wiring
1:
Sensor supply (US) L+
2:
DI
3:
Sensor supply (US) L-
4:
C/Q IO-Link
Ethernet IN / OUT X21, X22
Plug and socket connection
RJ-45
IoT X32
Plug and socket connection
RJ-45
