IFM Electronic CR0505 - Mounting

3.3 Mounting surface
The housing must not be exposed to any torsional forces or mechanical
stress.
Use compensating elements if there is no flat mounting surface available.
3.4 Heat dissipation
Ensure sufficient heat dissipation as the internal heating of the electronics is
conducted away via the housing..
In case of sandwich mounting of controllers use spacers.
ENGLISH
CLASSICCONTROLLER CR0505
PAGE 5
