49
UK
Contact rating
6 A , 250 V AC / 24 V DC (≥ 6 mA)
max� total current: 12 A
Minimum load current of the
feedback contacts
10 mA
Short-circuit protection / overload
protection
The contacts are to be protected by means of fuses
with a nominal current of < 3�6 A
Current consumption
< 500 mA
Function display
voltage (green), error (2 x red), output status (3 x
yellow), input (2 x yellow)
Power-on delay time
< 6 s
Duration of switch-off test pulses
≤ 500 µs
Response time [ms]
acc� to input circuit → chapter
8�1
8�2
8�3
8�4
8�5
Release
70
160
70
110
110
Safety requirement
30
100
30
30
30
Ambient temperature
-25���55°C
Protection rating
IP 20
Housing materials
PA
Input characteristics (S34, S43)
"1": > 11 V, 6 mA
"0": < 5 V, < 500 µA
Output characteristics
S33 push-pull short-circuit proof
"0": I
sink
~ 30 mA
"1": I
source
≥ 50 mA, U > 18 V
S44 "0": I
R
≤ 300 µA
"1": I
source
≥ 50 mA, U > 18 V
Y7 "0": I
R
≤ 300 µA
"1": I
source
≥ 11 V @ 30 mA, ≥ 15 V @ 15 mA
Mission Time (TM)
175 200 h
PFH
D
5,86 x 10
-9
/ h *)
B10
D
400 000 *)
