10
The properties of the LED segment are defined as follows:
Byte 0
Bit 3
Byte 0
Bit 2
Byte 0
Bit 1
Byte 0
Bit 0 Colour
0 0 0 0 off
0 0 0 1 red
0 0 1 0 green
0 0 1 1 orange
0 1 0 0 blue
0 1 0 1 violet
0 1 1 0 turquoise
0 1 1 1 white
1 0 0 0 yellow
Byte 0
Bit 6
Byte 0
Bit 5
Byte 0
Bit 4 Frequency
0 0 0 permanently on
0 0 1 low flash rate slow
0 1 0 low flash rate medium
0 1 1 low flash rate fast
1 0 0 high flash rate slow
1 0 1 high flash rate medium
1 1 0 high flash rate fast
