IFM DV2120 - Scale Drawings

14
9 Scale drawing
9.1 DV212x
Original Scale Drawing (MTD)
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 40,5 mm
P_MZ_e200_0103
M12x1
6110
2016,2
M30x1,5
56
M12x1
6110
2016,2
M30x 1,5
56
Dimensions [mm]
9.2 DV213x
Original Scale Drawing (MTD)
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 40,5 mm
P_MZ_e200_0102
M12x1
72,510
2016,2
M30x1,5
56
1
M12x1
72,510
2016,2
M30x 1,5
56
1
1: Buzzer
Dimensions [mm]
