iGenix IG9750 - Add Water; Ice Box Usage

8
Add Water
Add water from the top: Rotate Water Tank’s top cover, ll with water
Add water from the side: Rotate Water Tank’s side cover, ll with water
Fill water from
top Water Tank
Fill water from
bottom Water Tank
Put the Ice Box
into Water Tank
Filter Frame
Ice Box
IMPORTANT:
• When humidifying, the water level in the Water Tank must remain under the MAX indication;
replenish water if level drops below the MIN indication
• If the water level in the Water Tank is below the minimum scale marked on Water Display
Window, don’t use the humidication function
• When the water level is lower than the minimum scale, the unit will emit a 3 second warning
sound, after which the water pump will stop running.
• When the water level exceeds the maximum, the unit shall make 10 seconds buzzing warning
sound, to prevent the Water Tank overowing.
Ice Box
The ice box can absorb the heat in the water, which can lower the temperature of the water tank.
It can make the air ow cooler.
1. Take out the ice box and put it into the freezer, until the ice box is totally frozen.
2. Put the frozen ice box into the water tank.
