OPERATION
ELECTRONIC MONITOR PANEL
1. MONITOR LAMPS
c
Engine Oil Pressure Warning Lamp
When warning lamp comes on and the action alarm
sounds with the engine running, stop the engine.
This indicates insufficient oil pressure.
Check the engine oil level and have any necessary
repairs made before starting the engine.
d
Charge Warning Lamp
This indicates a malfunction in the electrical charging
system.
If the light comes on while the engine is running,
check the electrical system.
e Heat Indicator Lamp
Hold the engine start switch in the HEAT position for
approximately 15 seconds. The air heater is
activated and the indicator comes on.
j Engine Fail Lamp
The lamp flashes if the engine abnormality occurs
while the engine is running.
(1) Engine Oil Pressure
Warning Lamp
(2) Charge Warning Lamp
(3) Heat Indicate Lamp
(4) Fuel Level Gauge
(5) Water Temperature Gauge
