Iiyama ProLite TE8604MIS User Manual

ENGLISH
18 BEFORE YOU OPERATE THE MONITOR
CONNECTING YOUR MONITOR
Ensurethatboththecomputerandthemonitorareswitchedo󰀨.
Connect the computer to the monitor with the signal cable.
Connect the computer to the monitor with the Touch USB Cable.
Connect the computer to the monitor with the USB Type-C Cable when viewing images on your
monitor through the USB Type-C Connector or when using the monitor’s USB hub function.*
ConnectthePowerCabletothemonitorrstandthentothepowersource.
Turnonyourmonitor(MainPowerSwitchandPowerButton)andcomputer.
*

When charging connected device via USB Type-C Connector, check if the device is equipped
with aUSBType-CConnectorthatsupportschargingfunctionviaUSBPD(=PowerDelivery).

The connected device can be charged via USB Type-C Connector even when the monitor is in
standby mode.

The USB power delivery is up to 65W. If the connected device required more than 65W for
  operationorforbootup(whenthebatteryisdrained),usetheoriginalpoweradapterthatcame
with the device.

IfaseparatelypurchasedUSBType-CCableisused,makesurethecableiscertiedbyUSB-IF
and is full-featured with power delivery and video / audio / data transfer functions.

USB C to A cable is not included with the monitor. If you use a USB C to A cable, please note
that you can only transfer data.

Compatibilitywithallconnecteddevicesisnotguaranteedduetodi󰀨erentuserenvironments.

Make sure that the building installation has a circuit breaker of 120/240V, 20A
(maximum).

The signal cables used for connecting the computer and monitor may vary with the
type of computer used. An incorrect connection may cause serious damage to both
the monitor and the computer. The cable supplied with the monitor is for a standard
connector. If a special cable is required please contact your local iiyama dealer or
regionaliiyamao󰀩ce.

MakesureyoutightenthengerscrewsateachendoftheSignalCable.

The touch function is ready for use about 5 seconds after connecting the USB cable and
canbeoperatedwithapen,ngeroranyotherpointer.

The Class I pluggable equipment Type A must be connected to protective earth.

The socket-outlet shall be installed near the equipment and shall be easily accessible.

Excessive sound pressure from ear-/headphones can cause hearing damage/hearing loss.
NOTE

Iiyama ProLite TE8604MIS Specifications

General

Pixel pitch	0.4935 x 0.4935 mm
Response time	8 ms
Display diagonal	86 \
Touch technology	Multi-touch
Display brightness	350 cd/m²
Display technology	IPS
Native aspect ratio	16:9
Horizontal scan range	30 - 80 kHz
Touchscreen technology	Infrared
Contrast ratio (dynamic)	3500:1
Contrast ratio (typical)	1200:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	217.4 cm
Active display area (W x H)	1895 x 1066 mm
Number of simultaneous touchpoints	20
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	14 mm
Placement supported	Indoor
Bezel width (bottom)	43 mm
Panel mounting interface	800 x 600 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	390 W
Package depth	270 mm
Package width	2102 mm
Package height	1278 mm
Package weight	84300 g
Purpose	Universal
Number of OSD languages	9
Operating hours (hours/days)	24/7
Mean time between failures (MTBF)	50000 h
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS
Graphics card	Mali-G52
Internal memory	4 GB
Processor cores	4
Processor family	ARM Cortex
Processor architecture	ARM Cortex-A73
Internal storage capacity	32 GB
Operating system installed	Android
DVI port	-
Interface	USB
USB version	3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	5
Ethernet LAN data rates	1000 Mbit/s
HDMI input ports quantity	3
Ethernet LAN (RJ-45) ports	2
HDMI output ports quantity	1
Cables included	AC, HDMI, USB, USB Type-C
RMS rated power	32 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	86 mm
Width	1957 mm
Height	1159 mm
Weight	64400 g
