Iiyama ProLite TE8604MIS - ProLite TE7504 MIS Specifications

ENGLISH
APPENDIX 51
Touch
Screen
Technology IR Touch 20points
Light transmission 88%
Hardness 7H
Thickness 3mm
Communication
system
USB serial transfer
Response time 10ms
Size Category 75"
LCD
Panel
Panel technology IPS
Size Diagonal:74.52"(189.273cm)
Pixel pitch 0.4296mmH×0.4296mmV
Brightness 350cd/m
2
(Typical)
Contrast ratio 1200:1(Typical:withoutglass)
Viewable angle Horizontal:178degrees,Vertical:178degrees(Typical)
Response time 8ms(Typical,GraytoGray)
Display Colors Approx.1.07B
Sync Frequency
VGA: Horizontal: 30.0-80.0kHz, Vertical: 50-60Hz
HDMI1/2/3: Horizontal: 30.0-135.0kHz, Vertical: 24-60Hz
USB-C 3.1 Gen1: Horizontal: 30.0-135.0kHz, Vertical: 24-60Hz
Native Resolution 3840×2160,8.3MegaPixels
Supported max. resolution
VGA:1920×108060Hz
HDMI1/2/3:3840×216060Hz(YUV420/RGB444/YUV444)
USB-C3.1Gen1:3840×216060Hz
Input Connector VGA×1,HDMI×3,USB-C×1
USB Standard
USB2.0(DC5V,500mA)×1(forsoftwareupdate)
USB3.0(DC5V,900mA)×4(Front:2,Side:2)
USB-C3.1Gen1(5V,3A/9V,3A/12V,3A/20V,3.25A)×1
(DisplayPort1.4ALTmode/Touch/PowerDerivery65W)
Number of USB Ports
Connector shape
1 : Type C
2Upstream:TypeB(fortouch)
5 Downstream : Type A
Input Audio Connector ø3.5mmminijack(Stereo)
LAN RJ45×2
Serial Port RS-232C In
Plug & Play VESA DDC2B
TM
Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Analog:0.7Vp-p(Standard),75
Ω,
Positive
Digital:HDMI,USB-C3.1Gen1(DisplayPort1.4)
Input Audio Signal 2.0Vrms maximum
Output Connector HDMI3840×216060Hz
SPDIF out Connector SPDIF
Headphone Connector ø3.5mmminijack(Stereo)
SPECIFICATIONS : ProLite TE7504MIS
