IKA Plate - Operation

16 17
Operation
/// Start-up
/// Display
01 Set speed value
02 Set temperature value
03 Motor running / rotation direction
04 Timer / counter
05 Temperature unit
06 Heating function activated
07 Actual temperature value
08 Actual speed value
09 Temperature control mode
10 Operating mode
11 Safety circuit temperature
12 Viscosity trend value
13 |
14
PT 1000 temperature sensor connected
ETS-D5 / ETS-D6 connected
15 All parameters locked
16 USB connection with PC
17 Connection with PC established
18 Intermittent mode activated
SET
SET
SAFE
VISC
07 09 11 10 15 17 16 08
01
18030412050206
14 | 13
1.
2.
OFF
(°C / °F)
(rpm)
3.
4.
Temp 0...310 °C Speed 0...1500 rpm
SET
SET
SAFE
5.
ON
