Technical data
Base unit Value
Pump rate max. [m³/h] 1.32
Pump rate max. [l/min] 22
Final pressure without gas ballast [mbar] 2
Suction levels [-] 4
Cylinder [-] 4
Connection diameter suction side [mm] 8
Connection diameter pressure side [mm] 8
Input pressure min. [mbar] 2
Input pressure max. [mbar] 1030
Boiling point detection [-] yes
Solvent library [-] yes
Analog speed vacuum control [-] yes
Speed control [-] Turning knob
Display [-] TFT
Pressure unit / scale [-] mbar, hPa, mmHg, Torr
Vacuum sensor [-] yes
Vacuum sensor type [-] ceramic Al2O3
Pressure max. for pressure sensor [bar] 1.2
Measurement range (absolute) min. [mbar] 1
Measurement range (absolute) max. [mbar] 1030
Resolution pressure [mbar] 1
Measurement uncertainty [mbar] 1
Venting valve [-] yes
Condensate trap [-] yes
Emission condenser [-] yes
Timer [-] yes
Noise at low. pressure [dB(A)] 54
Material in contact with medium [-] Al2O3, PTFE, FPM, PPS
Housing material [-] Alu-cast coating
Mode automatic [-] yes
Mode manual [-] yes
Mode pump % [-] yes
Mode program [-] yes
Width [mm] 270
Depth [mm] 500
Height [mm] 435
Weight [kg] 14
Permissible ambient temperature min. [°C] 5
Protection class II
Overvoltage category !
Degree of contamination 1
Use above max. MSL m 2000
Firmware update yes
