made by means of a rigid copper or
steelpipewithttingscomplyingwith
local regulations, or by means of a
continuous-surface stainless steel hose
complyingwithlocalregulations.The
maximum length of the hose is 2 linear
metres.
A
B
C
C
D
D
- Connectelbow(A)or(B)suppliedwith
to the hob inlet main pipe and interpose
thewasher(C)supplied,incompliance
withEN549.
- Washer(D)notsuppliedwiththe
product.
- IMPORTANT: if a stainless steel hose
is used, it must be installed so as not to
touch any mobile part of the furniture.
Itmustpassthroughanareawhere
therearenoobstructionsandwhereitis
possible to inspect it on all its length.
- Afterconnectiontothegassupply,check
forleakswithsoapywater.Lightupthe
burnersandturntheknobsfrommax
position
to minimum position to
checkamestability
Electrical connection
WARNING
- This operation must be performed by a
qualiedtechnician.
- The electrical connections must comply
withlocalregulations.
- The earthing of this appliance is
compulsorybylaw.
L
N
Earth
(yellow/green)
- Do not use an extension cord.
- IMPORTANT: the data relevant to the
voltageandpowerabsorptionare
indicated on the rating plate.
Assembly
After having cleaned the perimeter surface,
applythesuppliedgaskettothehob.
Positionthehobintheworktopopening
made respecting the dimensions indicated in
the Instruction.
NOTE:thepowersupplycablemustbelong
enoughtopermititsupwardextraction.
Tosecurethehob,usethebracketsprovided
withit.Fitthebracketsintotherelevant
boresshownbythearrowandfastenthem
bymeansoftheirscrewsinaccordancewith
thethicknessoftheworktop.
