ENGLISH 14
Programme / Functions
compatibility
Functions
Spin
Start Delay Fresh Plus
Dry Only Drying setting
Mixed
White
Cotton
Eco 40-60
Delicates
Synthetics
Steam Care
Spin & Drain
Rinse & Spin
Quick 30’
Cotton 20°C
Wool
Wash & Dry 45'
Wash & Dry 90'
Cleaning and maintenance
For any cleaning and maintenance, switch o and unplug the
washing machine.
Do not use ammable uids to clean the washing machine.
CLEANING THE OUTSIDE OF THE WASHING MACHINE
Use a soft damp cloth to clean the outer parts of the washing
machine.
Do not use glass or general purpose cleaners, scouring powder
or similar to clean the control panel – these substances might
damage the printing.
CHECKING THE WATER SUPPLY HOSE
Check the inlet hose regularly for brittleness and cracks. If
damaged, replace it by a new hose available through our After-
Sales Service or your specialist dealer.
Depending on the hose type:
If the inlet hose has a transparent coating, periodically check
if the colour intensies locally. If yes, the hose may have a leak
and should be replaced.
For water stop hoses: check the small safety valve inspection
window (see arrow). If it is red, the water stop function was
triggered, and the hose must be replaced by a new one.
For unscrewing this hose, press the release button (if available)
while unscrewing the hose.
CLEANING THE MESH FILTERS IN THE WATER SUPPLY HOSE
1. Close water tap and unscrew the inlet hose.
2. Clean the mesh lter at the hose’s end carefully with a ne
brush.
