iLO DTV2784 - Parts and Functions

6
Parts and functions
Front
Rear
*VOLUME ▲/▼ buttons
POWER button
*CHANNEL ▲/▼ buttons
Remote sensor
AUDIO (L/R)/VIDEO IN jacks (VIDEO2)
* To display the menu screen.
Press both
VOLUME ▲/▼ buttons at the same time to display the menu screen.
CHANNEL ▲/▼ buttons and
VOLUME ▲/▼ buttons can be used to select the desired setting during the menu
screen operations.
AC power cord
S-VIDEO IN jack
COMPONENT IN jacks
AUDIO (L/R)/VIDEO IN jacks
(VIDEO1)
RF IN (VHF/UHF) jack
COAXIAL DIGITAL
AUDIO OUT jack
