ILVE ILD88B - Electrical Connection; Connection Requirements and Caution; Wiring Configurations

17
ELECTRICAL CONNECTION
x The installation of this appliance and the connection to the electrical network should be
entrusted only to an electrician following the normal regulations.
x Protection against the parts under tension must be ensured after the building-in.
x The information on connections necessary are on the stickers. Place them on the hob
casing near the connection box.
x Connection to the mains must be made using an earthed plug, which must be accessible
after installation, or via an omnipolar circuit breaking device with a contact opening of at
least 3 mm.
x The electrical circuit must be separated from the network by adapted devices, for example:
circuit breakers, fuses or contactors.
x If the appliance is not fitted with an accessible plug, a disconnecting means must be
incorporated in the fixed installation, in accordance with the installation regulations.
x The inlet hose must be positioned so that it does not touch any of the hot parts of the hob
or oven.
x If the electrical supply is restricted, means of all-pole disconnection must be accessible
and incorporated in the fixed wiring in accordance with the wiring rules.
Caution!
This appliance has only to be connected to a network 230 V~ 50/60 Hz.
Connect always the earth wire.
Respect the connection diagram.
The connection box is located underneath at the back of the hob casing. To open the cover use a
medium screwdriver. Place it in the slits and open the cover.
CONNECTION OF THE HOB FOR INB885B:
* calculated with the simultaneous factor following the standard EN 60 335-2-6/1990
Setting up the configurations:
For the various kinds of connection, use the brass bridges which are in the box next the terminal
Monophase 230V~1P+N
Put a bridge between terminal 1 and 2.
Attachtheearthtotheterminate“earth”,theneutral N to terminal 4, the Phase L to one of the
terminals 1 or 2.
Biphase 400V~2P+N
Attachtheearthtotheterminate“earth”,theneutralNtoterminal4,thePhaseL1tothe
terminals 1 and the Phase L2 to the terminal 2.
Caution! Be careful that the cables are correctly engaged and tightened.
Mains
Connection
Supply cord
Supply cord
Circuit braker
230V~ 50/60Hz
1 Phase + N
3 x 2,5 mm²
H 05 VV - F
H 05 RR - F
25 A *
400V~ 50/60Hz
2 Phases + N
4 x 1.5 mm²
H 05 VV - F
H 05 RR - F
16 A *
We cannot be held responsible for any incident resulting from incorrect connection or
which could arise from the use of an appliance which has not been earthed or has been
equipped with a faulty earth connection.
