22
iM3 Dental Systems
Silent Hurricane Compressor
Adjusting Regulator Air Pressure
With the Dental Unit pressurised and air lines turned ON, the black knob on top of the
regulator is pulled up from the locked to the free position to adjust air pressure (see picture
page 25). Depress the black knob after setting to lock pressure adjustment.
The regulator gauge registers working or air line pressure which may be increased by
turning clockwise and lowered by turning anti clockwise.
The pressure air line gauge will register the working pressure, which should be
80 psi. The large guage to the left indicates the pressure in the white air tank. The pressure
in the tank will read 0psi when empty to 110psi when full.
Warning
Unit starts automatically. Isolate power supply and relieve air
pressure by opening tank ON/OFF valve prior to commencing
non electrical service tasks.
"This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concern-
ing use of the appliance by a person responsible for their safety."
Danger
High voltage used on this equipment.
Isolate from mains before removing any covers, which should
only be carried out by a qualified electrician .
Ensure power outlet is adequately rated for this unit.
