10
3 Way Air/Water Syringe
Your choice of air, water, or fine mist spray. Depress the right-hand button for air (a) and
the left-hand button for water (b) and both for a fine mist (a&b).
The 3 way syringe is ideal for flushing away debris during prophys or drying areas during
endodontic procedures.
The selector switch, page 4 (d), allows you to choose either distilled water or CLS Enviro
Solution.
Tip Removal
The tip of the 3 way syringe may be removed for cleaning and autoclaving.
Simply depress the outer ring housing (c) and remove the tip. (See diagram below).
iM3 Dental Systems
Ultrasonic Scaler Coolant Outlet
The ultrasonic coolant outlet is located at the back of the elite control top. (see page 4)
This outlet provides coolant under pressure for an ultrasonic scaler. You can choose
between water or CLS Enviro Solution by setting the selector switch, page 4 (D).
(a)
(b)
(c)
(a) Air
(b) Water
(c) Outer Ring Housing
