SPECIFICATIONS / COMPONENT IDENTIFICATION
2-1
SECTION 2
SPECIFICATIONS / COMPONENT IDENTIFICATION
MODEL METRIC US DE30 lb. DE50 lb. DE75 lb.
Maximum Capacity (dry weight) kg lbs 13.9(35) 23(50) 34(75)
Basket Diameter mm. inch 762(30) 922(36.3) 922(36.3)
Basket Depth mm. inch 762(30) 762(30) 910(35.8)
Basket Volume cu. m. cu. ft. 0.34(12.2) 0.5(18) 0.6(21.5)
GAS:
Air Flow cmm. cfm 17(600) 21.25(750) 25(900)
Heat Input kcal / hr Btu / hr. 2260(90000) 32760(130000) 50400(200000)
Gas Inlet mm. inch 12.7(0.5) 12.7(0.5) 19(0.75)
Exhaust Duct mm. inch 203(8) 203(8) 203(8)
A – Machine Height mm. inch 1850(72.83) 2100(82.67) 1915(75.39)
B – Machine Depth mm. inch 1120(44.09) 1190(46.85) 1270(50)
C – Machine Width mm. inch 800(31.19) 1000(39.37) 1000(39.37)
Net Weight (approx.) Kg. lbs. 294(648) 348(767) 379(835)
Shipping Weight (approx.) kg lbs 304(670) 358(789) 390(860)
STEAM:
Air Flow cmm cfm 17(600) 21.25(750) 25(900)
Steam consumption BHP BHP 2.6 4.6 6.5
Operating Pressure
kg / cm²
psi 5.6-8.79(80-125) 5.6-8.79(80-125) 5.6-8.79(80-125)
Steam supply mm. inch 19.05(0.75) 19.05(0.75) 19.05(0.75)
Steam return mm. inch 12.7(0.5) 12.7(0.5) 12.7(0.5)
Exhaust Duct mm. inch 203(8) 203(8) 203(8)
A – Machine Height at full mm. inch 1900(74.8) 2200(86.61) 2140(84.25)
B – Machine Depth mm. inch 1120(44.09) 1150(45.27) 1270(50)
C – Machine Width mm. inch 800(31.19) 1000(39.37) 1000(39.37)
Net Weight (approx.) Kg. lbs. 307(677) 362(798) 385(849)
Shipping Weight (approx.) Kg. lbs. 315(694) 372(820) 396(873)
ELECTRICAL:
Air Flow cmm. Cfm 17(600) 21.25(750) 25(900)
A – Machine Height at full mm. inch 1880(46.45) 2100(82.67) 2100(82.67)
B – Machine Depth mm. inch 1120(44.09) 1150(45.27) 1270(50)
C – Machine Width mm. inch 800(31.19) 1000(39.37) 1000(39.37)
Net Weight (approx.) Kg. lbs. 308(679) 354(780) 382(842)
Shipping weight (approx.) Kg. Ibs. 317(699) 364(802) 393(866)
A. TECHNICAL SPECIFICATIONS
