Image DE 75 - Component Identification

SPECIFICATIONS / COMPONENT IDENTIFICATION
2-5
1. Dryer Model DE30, 50, 75 lb. Dryer Front View
No. Description
1 Timer controller
2. Front panel assembly, top
3. Front panel assembly, middle
4. Main door assembly
5. Front panel assembly, lower
6. Right side panel assembly
7. Left side panel assembly
Figure.2-4 Dryer Model DE30, 50, 75 lb. Front View
