4.8 DSUB-9 pin configuration
4.8.1 Display
DSUB-PIN
Signal
Description
Use in device
1
DCD
Vcc 5V
connected
2
RXD
Receive Data
connected
3
TXD
Transmit Data
connected
4
DTR
5V
connected
5
GND
ground
connected
6
DSR
Data Set Ready
connected
7
RTS
Ready To Send
connected
8
CTS
Clear To Send
connected
9
R1
Pulldown to GND
connected
4.8.2 Modem (external)
DSUB-PIN
Signal
Description
Use in device
1
DCD
Data Carrier Detect
connected
2
RxD
Receive Data
connected
3
TxD
Transmit Data
connected
4
DTR
Data Terminal Ready
connected
5
GND
Ground
connected
6
DSR
Data Set Ready
connected
7
RTS
Ready To Send
connected
8
CTS
Clear To Send
connected
9
nc
reserved
unused
4.8.3 GPS
DSUB-9
GPS 18 LVC
GPS 18 - 5Hz
Pin
Signal
Color
Color
1
Vin
Red
Red
2
RxD1*
White
White
3
TxD1
Green
Green
4
-
-
-
5
GND, PowerOff
2x Black
2x Black
6
-
-
-
7
PPS (1 Hz clock)
Yellow
Yellow
8
-
-
-
9
-
-
-
* Pin configuration at measurement device. At the GPS-mouse Rx and Tx are interchanged.
