imc CRONOS-PL/-SL/compact - Getting Started, Version 5 R 7 - 2018-06-28© 2018 imc Meßsysteme GmbH
Pin configuration of the field busses 45
4.9.4 FlexRay-Bus (DSUB-9)
imc standard: One DSUB-9 connector with two channels
DSUB-Pin
Signal
Description
1
nc
2
BM channel A
negative bus line channel A
3
GND
FlexRay ground
4
BM channel B
negative bus line channel B
5
GND
FlexRay ground
6
nc
7
BP channel A
positive bus line channel A
8
BP channel B
positive bus line channel B
9
nc
Option: Two DSUB-9 connectors (CON1 and CON2) with one channel each
DSUB-Pin
CON1
CON2
1
nc
nc
2
BM channel A (negative bus line channel A)
BM channel B (negative bus line channel B)
3
GND
GND
4
nc
nc
5
GND
GND
6
nc
nc
7
BP channel A (positive bus line channel A)
BP channel B (positive bus line channel B)
8
nc
nc
9
nc
nc
4.9.5 XCPoE (RJ45)
Standard Ethernet 1x RJ45.
4.9.6 EtherCAT (RJ45)
Standard Ethernet 2x RJ45
